Restoring and Racing the YDS and TD Yamaha's

YDS1R - YDS2R - TD1A - TD1B - TD1C - TD2 - TD2B

"Help me preserve and keep the Yamaha's Racing"


E-Mail me if you have any obsolete spare parts or tuning information



SWAP or FOR SALE




Surplus NEW and USED Yamaha Road Race Spare Parts

1 x NEW TD1 piston - 0.75 mm thick ring groove, 15 mm gudgeon pin, size 95

1 x NEW TD1 piston - 0.5 mm thick ring groove, 15 mm gudgeon pin, size 95

1 x NEW 144-25434-00 TD1 alloy rear sprockets, 34 teeth, to suit 525 chain

1 x used 144-25434-00 TD1 alloy rear sprocket, 34 teeth, to suit 525 chain

5 x NEW 144-81526-00 TD1 Hitachi condensers

3 x NEW 90340-14033 sump plugs, drilled for lock wire

1 x NEW 240-23114-00 O-ring for TD2 fork (aluminium) cap

2 x used left TD2 cylinders

1 x used pair of TD2B cylinders

1 x used right TD2B cylinder

2 x used 240-11181-00 TD2, TD2B copper cylinder head gaskets
which have been annealled to make them soft again

3 x NEW 240-11181-00 copper head gaskets to suit the TD2 and TD2B

10 x NEW 152-11685-00 or 90209-24073 crank thrust washers (silver plated)
to suit TD1B, TD1C, TD2, YDS3, YDS5 and YDS6


2 x NEW YZ125 5X4-11611-02 chromed faced piston rings, 0.80 mm in thickness
to suit TZ 250 J / K / L models with the 56 mm bore size for those who want a good ring for a nicosil bore cylinder


145-28371-00 TD1B & TD1C "replica" front fairing mounting rubber

1 x used TZ125H piston (glass bead peened) suitable for TD2, TD2B and TZ500

1 x used TD2 piston (glass bead peened) suitable for TD2 and TD2B

2 x NEW Genuine and MODIFIED 156-11631-20 DS3 / YDS3 + 0.25 mm = 56.25 mm pistons
* The outside face if the top ring land has been machined (to prevent the ring from overheating)
* The piston skirt has been shortened by approx 10mm (to allow more air/fuel to flow from the inlet tract to keep the piston and cylinder wall well lubricated and cooler.)
* 2 holes have been drilled in each of the gudgeon pin boss (for additional oiling of the gudgeon pin and to prevent galling.)
* Pistons have been glass bead peened (to produce a good and hard surface, the pistons were then "Scotch Brite" hand finished to produce good surface a characteristics.)


1 x used TD1B ignition side cover - glass bead blasted.

1 x used TD1 / TD1B / TD1C alloy rear brake activating arm for the brake cam.

1 x used TD1 MF-2RY magneto


Various used TD1A, TD1B, TD1C and TD2, TD2B motor parts available
Please email me your list of items wanted!




Surplus NEW and USED Racing Spare Parts

2 new x Femsa ignition coils, FA95-66 BF
**** make an offer ****

2 x NEW Ferodo FM2 brake linings to suit 9 inch diameter drum brake.
37 mm wide x 5.5 mm thick x 230 mm long (measured along the arc).
Each piece has 12 x pre drilled rivet holes and is supplied with brass coloured rivets.





Surplus NEW and USED Yamaha Road Spare Parts

4 x NEW Hitachi M43 spark plugs, HALOX porcelain insulator (same as the optional NGK B-7HZ)
**** make an offer ****

1 x NEW 246-1311-00 DS6 / YDS6 left hand cylinder, bore size 0.000

3 x used pairs of DS6 / YDS6 cylinders

1 x used pair of DS6 / YDS6 cylinder heads

1 x used DS6 / YDS6 right cylinder head

1 x used pair of DS2 / YDS2 cylinders

1 x used pair of DS1 / YDS1 cylinders

1 x used DS1 / YDS1 front brake drum

1 x used DS5 / YDS5 kickstarter

2 x NEW Genuine 156-11636-00 DS3 / YDS3 + 0.50 mm pistons (with Moly anti friction coating)

1 x NEW 156-15371-00 oil vent breather, rubber plug with hose

1 x used DS1 / YDS1 LIBERTY RANCH MODEL frame and swingarm

1 x used DS1 / YDS1 LIBERTY RANCH MODEL petrol fuel tank

used DS1 / YDS1 LIBERTY RANCH MODEL engine parts available

1 x used DS6 / YDS6 oil tank with no cap

1 x used DS6 / YDS6 air filter box


If anyone is looking for the matching engine then these may suit your needs:

1 x used DS6 / YDS6 matched pair of crankcases stamped DS6-107506

1 x used DS6 / YDS6 matched pair of crankcases stamped DS6-112487

1 x used DS5 / YDS5 left hand crankcase stamped DS5-22780



Various USED DS1 / YDS1, DS2 / YDS2, DS3 / YDS3, DS5 / YDS5 and DS6 / YDS6 parts available
Please email me your list of items wanted!



Surplus USED Yamaha XS650 Road Spare Parts

1 x Used XS650 front disc brake hub with side screw plate with disc carrier and disc - probably a double sided disc hub; will need to check by removing the side cover plate

1 x Used XS650 BIG front drum brake complete with axle and laced with a 19 inch steel rim



1 x NOS YUASA 6N11A-1B Battery

Yuasa Battery Co Ltd - Made in Japan

DRY Battery - Never had battery acid added - just add acid and recharge



Surplus Genuine Yamaha Factory Literature (Memorabilia)


SERVICE / WORKSHOP MANUALS
SPARE PARTS BOOKS
OWNERS HANDBOOKS (they usually come with a new bike)
MODEL GUIDES
OTHER YAMAHA BOOKS & PUBLICITY KITS
SERVICES DATA SHEETS
MICROFICHE OF SPARE PARTS BOOKS
SALES BROCHURES


YAMAHA SERVICE / WORKSHOP MANUALS

MF3D 50 cc / U7 75 cc
XS1100E
PW50J
PW50H
XS750F Supplementary Manual
125AT2 J (E) / 175CT2
MF(J) 2 50 cc
HT1
AT1
360 RT1-B
125 A6
L2G 100 cc
YZ100H
XS1100E
YZ50K
PW50T
DT125G/DT175G Supplementary Service Manual
XJ750RH
IT175G
PW50H
XS750D - 2 Copies
DT100D
RS100
GT1/GT MX
GT50B/GT80B/GT MXB
SA50
IT200S
PW80S
XS657SF
AG100G
YZ50J
PW50L
PW50K
PW80L
DT125F/DT175F
Shaft Drive Service Manual
PW50N
1963-1971 Rotary Valve Singles - Clymer Publication
SX250E/XS400E
RD125B/200B
JT1 Supplementary Service Manual
SR500E
R3 / R3C
Yamaha 50
125 AS3
SR500F
YDS1
YDS2
YDS3 / YM1


YAMAHA SPARE PARTS BOOKS
GT80G (2F6)
YZ50G (3RO)
DT125G (3T6)
DT125F (3A4)DT175F(3H8)
DT100G (1X1)
XS1000F (2U6)
XS750SF (3J9)
CS5E
YA6 DEC 1967
TD2 with TD2B Supplement
DT1
SR500E
SR500F Supplementary Parts List
YDS1
YDS2
YDS3 / YM1
TD1C



YAMAHA OWNERS HANDBOOKS (these usually come with a new bike)

XV750J
XS250F/XS400F
50MF3 - D
XJ750 RH
XV1000MK
XJ650H
DT100B - DT360B All models 1982
XT250TL
XZ500RJ
MX50H
XT600L
XT650B 1980
RS100/RS100DX RS125/RX125H 1985
XS400RK
XS1100H 1981
XT125K/XT200K
XJ650RK
XS360D
DT125H/DT175H
AG100
SR250K
XV1000N
XT250K
250DT3/360RT3
MX80J
250 DS7
DT80H
SR185J
Yamaha Warranty Guide
YD2
TD1C
YDS2


YAMAHA MODEL GUIDES

XS250E 1978
SX750E 1978
GT80E 1978
DT125E/DT275E 1978
XS400E 1978
XS250F/XS400F
SR500E
SR500F


OTHER YAMAHA BOOKS & PUBLICITY KITS

1987 MODELS - PRESS RELEASE KIT
COMMON SENSE TIPS FOR SAFE SPORTCYCLING
XV1000/XV750 - PUBLICITY KIT
TROUBLE SHOOTING MANUAL MAY 1970


YAMAHA SERVICES DATA SHEETS

RD250A NOV 1972 - 2 Copies
RD125A DEC 1973
TX650A DEC 1973
YB50/YB60 - 2 Copies
RD250 DEC 1972
RD125B DEC 1974
V50/V50E MAY 1975


YAMAHA MICROFICHE OF SPARE PARTS BOOKS

XT250H AUG 1980 - 2 copies
AG127H SEP 1980
DT250H SEP 1980
AG100H OCT 1980
YZ60H JUL 1980
DT100H JUL 1980
DT125H JUL 1980
DT175H JUL 1980
YZ50H JUN 1980
DT80H JUN 1980
SR250H JUL 1980
SR185J JUN 1981
PW50J JUN 1981
XT250J AUG 1981
SR250J SEP 1981
TT250J NOV 1981
YZ100J DEC 1981
XT200J JAN 1982
SA50H JUL 1980
LB80IIA JUL 1980
PW50H AUG 1980
RX125H JUL 1980
YAMAHA SPARE PARTS PRICE LISTING 1981 - 3 PARTS


SALES BROCHURES

1994 Yamaha Street Lineup covering the
YZF600R GTS1000A YZF750R YZF750SP FZR1000 FJ1200 SECA II XV1100 XV535 XV250
(LIT-3M3-0105003-94E 039502, 210 mm wide x 295 mm high
tri-fold equivalent to 4 pages printed both sides, dealer stamp)

YDS2 250 1962 New Yamaha Sports Model
(215 mm wide x 300 high, single page printed both sides, fold lines & creases)

YDS2 250 1962 250S 25 hp New Sports Model
(185 mm wide x 255 mm high, single page printed both sides, dealer stamp)

YDS3 250 cc 5-Speed Sport
(265 mm wide x 185 mm high, single page printed both sides, dealer stamp)

YM2 Yamaha Sport 305
(Ref. No. 300E, 185 mm wide x 265 mm high, single page printed both sides)

Yamaha 250 YDS2
Reprint of the August 1962 - CYCLE Magazine Road Test (Number 120)
(215 mm wide x 280 mm high, single fold equivalent to 2 pages printed both sides,
black & white, fold lines & creases)

Yamaha YDS2 Sports
Reprint of the January 1963 - Motorcycle Mechanics Magazine Road Test on the
(210 mm wide x 265 mm high, single fold equivalent to 2 pages printed both sides,
fold lines & creases)





WANTED

TD2B Clutch Boss


Yamaha Part Number: 240-16371-00




Not to be confussed with a TR2B clutch boss






Send me an email if you have a TD2B clutch boss that is surplus to you needs.




WANTED

TD2B - TR2B Clutch Pressure Plate


Yamaha Part Number: 239-16326-00



WANTED

TD2B - TR2B Clutch End Plate


Yamaha Part Number: 239-16352-00





Yamaha Racer are available

Click here to view the Racer For Sale



TD 250 Register for the Restoring and Racing
of the TD Yamaha's from the 60's - 70's

Click here to enter the Register of TD1 - TD1A - TD1B - TD1C - TD2 - TD2B Racing Yamaha's.




E-Mail for more information

"Help me preserve and keep the YDS and TD Yamaha's Racing"


View my Racing Yamaha's
